Second-hand 1820x16mm Spiral pipe machine
Pipe diameter: φ457-φ1820mm, Wall thickness: 4-16mm
1. Coil technical specifications
Material: Q235
Coil thickness: 4-16 mm
Coil width: 600-1500 mm
Coil inner diameter: Φ508-Φ610 mm
Coil outer diameter: Φ1200-Φ1800 mm
Maximum coil weight: 30 tons
2. Pipeline technical specifications
Pipeline outer diameter: Φ457 mm-Φ1820 mm
Pipe thickness: 4-16 mm (YS≤250MPA)
Pipe thread pitch: Max.2350 mm
Length: 8.5-12.5 meters
3. Specifications of grinding technology
Molding method: non-continuous production front axle swing type
Conveying speed: 0-2.5 meters/minute
Welding speed: 0-2.5 meters/minute
Grinding power supply: 220V/380V, 50HZ
Air compressor: 0.6 Mpa, 0.9 m³/min
Production capacity: 22,000-32,000 tons
4. Machine list
1) Uncoiler (1 unit)
2) Pinch roller and leveler (1 set)
3) Hydraulic vertical roller (2 sets)
4) Cutting and welding (1 set)
5) Edge milling machine (1 unit)
6) Cleaning device (1 set)
7) Manual vertical roller (1 set)
8) Delivery machine (1 unit)
9) Guide beam (1 set)
10) Forming machine (1 unit)
11) Front axle (1 set)
12) Internal welding device (1 set)
13) External welding device (1 set)
14) Walking platform (1 set)
15) Rear axle (1 set)
16) Cutting (1 set)
17) Centering device (1 set)
18) Hydraulic system and pipeline system
19) Electrical system
